COMPRESSED AIR SYSTEM FEATURE

Oil-Free, Reciprocating, High-Pressure Air Compressor

Packages for Stretch Blow Molding

    The stretch blow molding (SBM) process begins when preforms, created by injection molding machines, are supplied to a multilevel rotary wheel blow-molding system. In the first of a two-stage process, compressed air is injected into each preform through a stretch rod at between 101-203 psi as the stretch rod itself simultaneously pushes the material into a closed mold chamber. The blow stem then stops before it reaches the end of the mold. The second stage begins when compressed air is injected into the mold at between 377- 522 psi so it fully forms into the shape of the container. After each container is fully formed, high-pressure air is routed back through a feedback loop to be reused as low-pressure air for the first stage.

    Logoplaste wall-to-wall manufacturing designs often see the plastic product production equipment powered by HORIZON 3000 oil-free, reciprocating high-pressure air compressor packages designed and manufactured by ABC Compressors. The two firms have worked together to install compressed air systems at multiple locations within the United States. The HORIZON 3000 air compressor package features a variable speed drive (VSD) 610-horsepower (hp) air compressor rated to deliver up to 1,715 scfm of air at 580 psi (40 bar). Each package includes refrigerated dryers rated at 37°F (3°C) pressure dew point, as well as an electronic condensate drain and filters. “Unlike other high-pressure reciprocating air compressors, ABC Compressors’ HORIZON air compressors feature horizontally configured
